Key point: dB always expresses a ratio. Suffixes such as dBm, dBV, dBu, dBc, and dBFS state the reference that makes that ratio an actionable level. Without a reference—and an impedance where needed—a decibel value is incomplete.

Quick reference

Decibels compress very large ratios into numbers that are easy to add. A chain of RF gains and losses can therefore be handled with simple algebra in dB.

dB is a logarithmic ratio

For two powers:

L(dB) = 10 × log10(P2 / P1)

For two voltages or two currents, only when both impedances are the same:

L(dB) = 20 × log10(V2 / V1) = 20 × log10(I2 / I1)

The factor of 20 follows from power being proportional to the square of voltage at fixed resistance: P = V² / R.

Useful shortcut: +3 dB approximately doubles power, but increases voltage by only about 41%. +6 dB nearly doubles voltage and quadruples power.

Gain, loss, and cascade addition

An amplifier of +12 dB followed by a cable of −2.5 dB and a filter of −1 dB gives:

total gain = +12 − 2.5 − 1 = +8.5 dB

With an input of −20 dBm, ideal output is −11.5 dBm. This works for power gains and losses using a consistent convention, provided devices stay below compression and saturation.

Do not mistake a 3 dB insertion loss for 3% loss: it passes only about 50% of the power.

dBm and dBW: referenced power levels

dBm is referenced to 1 milliwatt:

P(dBm) = 10 × log10(P(mW))
P(mW) = 10^(P(dBm) / 10)

dBW is referenced to 1 watt:

P(dBW) = P(dBm) − 30
P(dBm) = P(dBW) + 30

dBm describes real power without assuming impedance. Impedance matters when translating that power into voltage or current.

dBV and dBu: referenced voltage levels

dBV is referenced to 1 V RMS:

V(dBV) = 20 × log10(VRMS / 1 V)
VRMS = 10^(V(dBV) / 20) V

dBu is referenced to 0.775 V RMS, the voltage that once dissipated 1 mW in 600 Ω:

V(dBu) = 20 × log10(VRMS / 0.775 V)

The difference between dBu and dBV is about 2.21 dB: 0 dBu = −2.21 dBV. dBu is now a voltage reference; it does not imply a 600 Ω load is present.

Power-to-voltage conversion: impedance is essential

For a resistive load R and RMS voltage:

P = V² / R
V = √(P × R)

Combined with dBm and dBV references:

dBm = dBV + 10 × log10(1000 / R)
dBV = dBm + 10 × log10(R / 1000)

RF example: +10 dBm into a matched 50 Ω load is 10 mW and 0.707 V RMS. With a mismatched load, measured voltage can differ because power is reflected.

dBc and dBFS: specialist relative levels

dBc means dB relative to carrier. A harmonic at −40 dBc is 10,000 times less powerful than the carrier. With a +10 dBm carrier, that harmonic is ideally at −30 dBm:

−40 dBc + 10 dBm = −30 dBm

dBFS means dB relative to digital full scale. 0 dBFS is the maximum representable level, so useful signal values are negative, such as −18 dBFS. Conversion to dBu or dBV depends on the converter maker’s specified analogue alignment.

A reliable calculation method

1. Identify the quantity: power, voltage, current, or digital level.
2. State the reference: 1 mW, 1 V RMS, 0.775 V RMS, carrier, or full scale.
3. For power-to-voltage conversion, state impedance and check that it is resistive and matched.
4. Use 10 × log10 for power, and 20 × log10 for voltage/current at equal impedance.
5. Keep RMS, peak, and peak-to-peak separate. For a sinewave, Vpeak = √2 × VRMS.
6. Add gains and losses in dB only after checking compatible levels.

Use the decibel converter to convert dB, dBm, dBW, dBV, and dBu with the appropriate reference.

Common laboratory pitfalls

• Using 20 log for power. Power requires 10 log10.
• Converting dBm to volts without an impedance. There is no single voltage for 0 dBm: it is 224 mV RMS in 50 Ω and 775 mV RMS in 600 Ω.
• Mixing RMS, peak, and peak-to-peak. Confirm the instrument setting and waveform.
• Forgetting 50 Ω termination. A generator specified for a 50 Ω load may appear to deliver twice its set voltage when open-circuit; check its display convention.
• Confusing dB and dBm. +6 dB is a relative gain; +6 dBm is an absolute power of 3.98 mW.
• Directly adding uncorrelated sources. Add their powers linearly, then convert back to dB. Two equal uncorrelated sources give +3 dB, not +6 dB.

Worked RF power budget

A source provides +5 dBm. The signal passes through a cable with 1.2 dB loss, a 0.8 dB filter, then a 15 dB amplifier.

Amplifier input = +5 − 1.2 − 0.8 = +3 dBm
Ideal output = +3 + 15 = +18 dBm

+18 dBm is about 63.1 mW. In a matched 50 Ω system, that is about 1.78 V RMS. Then verify amplifier maximum rating, filter power handling, and any reflections: a link-budget calculation does not replace those checks.
